Stainless Steel Plate
Model
-
Series
Stainless Steel Plate
Product Description

Basic Application Scope for Ordering DKC's Products

- Maximum Weight for Single Piece : 12,000kg
- Minimum Order : 6,000kg per size (excluding stocks)
- Delivery Time : two months after the order
- Delivery permit Limit : +/- 10% of total
- Extra Charge : Thickness and hardness
- Maximum Thickness : 120mm
- Maximum width : 3,400mm
- Maximum Length : 14,500mm



Measured Weight of Products
DKC products are supplied to customers by measured theoretical weight. But, the case of export products measured by the actual weight can be supplied when buyer demands.

- Actual weight : Actual weight when requested
- Theoretical weight :(thickness*width*length)*specific gravity



Products table of specific density
Spec.GradeDensity(kg/㎡)
JIS G 4304(SUS)304/304L, 3217.93
316/316L7.98
ASTM, ASMEAll Grades8.07



DKC Products inspection
Inspection certificate automatically issues in normal orders, For all other orders, inspection by authorized third member is optional.
(Additional cost for third party member inspection)











Wrapping

Basic wrapping when shipped but single/multi SKID packing is optional under demanders' request.. In that case, additional cost for third party member inspection.

A. Marking


B. Side


C. Shipping Mark




Available Range

STS Plate

* Grade : 304 / 304L / 304H / 304N/ 304N1 / 316 / 316L / 316H / 316Ti / 316L / 316LN



* Grade : 309S / 310S / 317L / 321 / 321H / 347 / 347H


* Grade : 329J3L / S31803 / S32205 / S32750 / S81921 / S32304 / S82121 / S31254 / 410UF

Product List
Stainless Steel Plate
